FH-L Emergenza New

Proiettore per condizioni estreme in esterno

Apparecchio di grandi dimensioni e grandissima potenza luminosa in versione emergenza.



  •  Apparecchio progettato per resistere alle condizione più estreme in ambito outdoor.
  •  Proiettore da esterni dotato di staffa goniometria di fissaggio.
  •  Flusso luminoso fino ad oltre 32000 lm. Disponibile in versione Smart Driver Autodimmerabile, controllabile da Centrale, o con sistema RD dotato di selettore per impostare 4 step di flusso luminoso.
  •  Doppio riflettore in alluminio sia simmetrico, che asimmetrico (asportando deflettore).
  •  Indicato sia come proiettore che come riflettore.
  •  Possibilità di inseire il modulo domotico e l'inverter per emergenza





Scopri il Sistema di controllo Smart Driver Beghelli



Versions
SD
Plus
Grande flessibilità di movimento e di installazione.
Specifications
Riflettori / Proiettori
Installations
Wall , Suspension , Floor
Body
Alluminio pressofuso verniciato alle polveri di poliestere RAL 7040
Optic
Lamellare a sviluppo parabolico in alluminio anodizzato brillantato antiridescente, Simmetrico, Asimmetrico
Screen
Vetro temprato prismatizzato 4mm
Power supply
SD: elettronico a dimmerazione intelligente
Equivalent power (W)
70, 150, 200
Light source
LED
Power supply (V)
UniversalMultyVoltage 93÷265Vac-50/60Hz 176÷250Vdc
Compliance
EN 60598-1, EN60598-2-1, EN60598-2-22(requisiti fondamentali), EN62471(rischio biologico esente), EN61493
Degree of protection
IP66
Room temperature
-20°+40°C
Colour temperature (K)
4000
Energy class
A++
RA (>)
80
Industriale
Appliance suitable for installations in schools, hospitals, office buildings, industrial facilities
Eco
Designed for energy efficiency, recyclability and reduction of parts subject to wear
IK09
Impact protection
IP66
Degree of protection against external factors
PlugLight
Quick connect Plug and Light with no affect on performance
UVOil
Appliance with UV radiation and mineral oil resistance
SD
Fixture can be interfaced with SmartDriver System
CE
Fixture complies with the European Community directives
950Degrees
Indicates temperature resistance of the product, as verified using the glow wire test
Palestra
Suitable for installation in gyms (UNI DIN 9554 18031-3)
Available in: EU
Specifications
Proiettore per condizioni estreme in esterno

FHL LED sono apparecchi di nuovissima generazione in grado di combinare i vantaggi della sorgente luminosa LED con sistemi ottici all'avanguardia, sia per il rendimento che per la grande flessibilità applicativa. Le sorgenti LED, ad elevatissima efficienza, impiegate producono un illuminamento senza precedenti che consente di illuminare facciate di edifici, o piazzali, anche da elevata distanza. Lo schermo ha un'area emittente ampia ed uniforme, tanto da conseguire bassissima luminanza, quindi abbagliamento ridottissimo ed elevato comfort visivo. Le ottime caratteristiche meccaniche (IP66- IK09) ne consentono l'installazione in ambienti esterni anche in condizioni estreme, inoltre, la possibilità delle versioni con fascio simmetrico o asimmetrico, rendono l'apparecchio particolarmente versatile.

Il design "quadrato" consente movimenti a 360°, sull'asse di rotazione della staffa goniometrica, permettendo quindi grande flessibilità di movimento e di installazione.
È disponibile un INVERTER che trasforma l’apparecchio in apparecchio di emergenza funzione SA, per accendere una sezione della sorgente LED in caso di black out. Riflettore a fascio controllato per ottimizzare la gestione della luce emessa. Ottica simmetrica e asimmetrica in un unico apparecchio: il fascio luminoso diventa da asimmetrico a simmetrico semplicemente asportando parte del gruppo ottico.

Details
Installazione - Installations
Suolo
Ground





Parete
Wall
Sospensione
Suspension
Palo con testa accessorio non incluso.
Pole with accessory head not included.
Palo con testa accessorio non incluso.
Pole with accessory head not included.
Ottica - Optics
Versione con ottica simmetrica/asimmetrica.
Version with symmetric / asymmetric optic.
Emergenza - Emergency
Emergenza con accessorio non incluso.
Emergency with no included accessory.
Accessori - Accessories
Staffa goniometrica inclusa.
Protractor bracket included.
