Formula 65 LED

Design e versatilità per molteplici applicazioni

Apparecchio per illuminazione di emergenza caratterizzato da una grande flessibilità di utilizzo. Grazie alla simmetria e all’estrema uniformità di illuminamento che la contraddistinguono, Formula 65 LED può essere installata, senza un orientamento predefinito, a parete, a plafone, a bandiera e a incasso.
Il corpo in policarbonato bianco ospita nel suo interno un’ottica a doppia riflessione  che a sua volta integra due serie di LED ad elevatissima efficienza. Lo schermo, in policarbonato ad elevata trasparenza, è stato progettato per sigillare il gruppo ottico e ottenere il Grado di protezione IP65. Sul guscio esterno del prodotto sono predisposti numerosi ingressi in prerottura per il fissaggio diretto su tutte le più diffuse scatole di derivazione e da incasso.


Autonomia regolabile e possibilità di batteria supplementare per raddoppiare il flusso (Batteria Autoripara).

Grande flessibilità grazie a molteplici versioni ed accessori per tutte le esigenze di installazione.

Corpo con numerosi ingressi in prerottura e il fissaggio diretto su scatola di derivazione.
TR - Tradizionale
LED di verifica della batteria e possibilità di regolazione dell’autonomia (1h-3h)
AT - AutoTest
Diagnosi locale (batteria, sorgente, circuito) e autonomia regolabile agendo sul circuito (1h-3h) o da App B.connect (1h-1.5h-2h-3h-8h)
CT - CentralTest autoalimentati
Diagnosi centralizzata nativa Cablecom per l’immediato collegamento con una Centrale CentralTest. Moduli aggiuntivi per espansione a LG, LGFM e DALI
CTS - CentralSystem alimentazione centralizzata
Batterie e diagnosi centralizzate per apparecchi rinnovati, disponibili in versione 230Vdc, ma anche in versione 24Vac, garantendo la massima sicurezza dell’impianto
HT - Da rete 230V o soccorritore / sistema DALI
Apparecchi alimentati da tensione di rete, soccorritori, sistemi LG230, controllo DALI (HT-DALI)

Approfondisci: SISTEMI DI CONTROLLO
Versions
SE,SA
Plus
grande versatilità di utilizzo
Autonomy
1h, 1.5h, 2h, 3h, 8h
Installations
Wall , Recessed
Body
Policarbonato, bianco RAL 9003
Optic
Simmetrica bianca
Screen
Policarbonato trasparente
Equivalent power (W)
6, 8, 11, 24, 36
Control system
TR, AT, LG/LGFM, HT
Light source
LED
Power supply (V)
230Vac±10%, 50÷60Hz (Sistemi LG230, LG24, HT considerare i parametri della centrale utilizzata)
Compliance
EN 60598-1, EN 60598-2-2, EN 60598-2-22, UNI EN 1838, UNI 11222, EN62034
Degree of protection
IP65
Room temperature
0°C +40°C, -20°C +45°C
850Gradi
Indicates temperature resistance of the product, as verified using the glow wire test
IK07
Impact protection
IP65
Degree of protection against factors
DoppioIsolamento
Apparatus with class II insulation level.
TenYears
Nube
BConnect
UVoxy
Available in: EU
Specifications
Applicazioni: Industriale, terziario
Tempo di ricarica: 12h con batteria LTO e LiFe
